UltraTemp® High-Performance Pool Heat Pump
An energy-efficient, cost-effective solution for heating pools and spas.

• First heat pump using R410A refrigerant, which is non-ozone depleting.
• 100% titanium heat exchanger ensures corrosion-free performance and long life.
• LCD control board with easy-to-read, intuitive full-word messages.
• AutoSet feature monitors water temperature, adjusting the pump to maintain desired heat.
• Automatic defrost prevents freezing, enabling operation at lower temperatures.
• Compatible with all automated control systems.
• Durable, corrosion-resistant plastic composite cabinet designed for harsh climates and pool chemicals.
• ETL listed for safety.
• Thermostatic Expansion Valve (TXV) optimizes refrigerant flow for maximum efficiency and output.
• Meets or exceeds all efficiency standards and codes, certified by AHRI.

Support Documents:

• UltraTemp High-Performance Heat Pump
• UltraTemp Heat Pumps Installation and User's Guide
• UltraTemp Autoset Kit Manual
• How to Size a Pool Heater: BTU Quick Reference Chart

Specifications:

• Brand: Pentair
• Application: Outdoor, Pool, Spa
• Shipping Dimensions: 43 x 34 x 51 inch
• BTU Output: 140000 British thermal unit
• Cabinet Depth: 33.8 inch
• Cabinet Height: 34.5 inch
• Cabinet Width: 38.9 inch
• Compressor Type: Scroll
• Control Type: Digital
• Weight: 344 pounds
• Flow Rate Max: 120 gal/min
• Flow Rate Min: 30 gal/min
• Frequency Rating (Hz): 60
• Green or Energy-Efficient Product: True
• Housing Material: Plastic
• Min Circuit Ampacity: 43 amperage
• Phase: Single
• Refrigerant Model: R410A
• Standards Approvals: AHRI Certified
• Voltage: 230V
• Commercial, Residential, or Professional: Residential
• Electrical Input: 7.3 kilowatts
• Heat Exchanger Material: Titanium
• Maximum Circuit Breaker: 50 amperage
• UPC Code: 788379859817
