by Pentair Pool
Pentair UltraTemp 120Q Heat Pump Almond, 460833
SKU 460833
TradeGrade
Pentair UltraTemp 120Q Heat Pump Almond, 460833
An energy-efficient, cost-effective solution for heating pools and spas.
- First heat pump using R410A refrigerant, which is non-ozone-depleting.
- 100% titanium heat exchanger ensures corrosion-free performance and long life.
- LCD control board with easy-to-read, intuitive full-word messages.
- AutoSet feature monitors water temperature, adjusting the pump to maintain the desired heat.
- Automatic defrost prevents freezing, enabling operation at lower temperatures.
- Compatible with all automated control systems.
- Durable, corrosion-resistant plastic composite cabinet designed for harsh climates and pool chemicals.
- ETL listed for safety.
- Thermostatic Expansion Valve (TXV) optimizes refrigerant flow for maximum efficiency and output.
- Meets or exceeds all efficiency standards and codes, certified by AHRI.
Support Documents:
Specifications:
- Brand: Pentair
- Amperage: 50 amperage
- Shipping Dimensions: 34 x 44 x 54 inch
- Application: Outdoor, Pool, Spa
- BTU Output: 127000 British thermal unit
- Commercial, Residential, or Professional: Residential
- Compressor Type: Scroll
- Control Type: Digital Electric
- Weight: 300 pounds
- Flow Rate Max: 120 gal/min
- Flow Rate Min: 30 gal/min
- Frequency Rating (Hz): 60
- Fuel Type: Electric
- Green or Energy Efficient Product: True
- Heat Exchanger Material: Titanium
- Housing Material: Composite
- Ignition Type: Digital
- Maximum Circuit Breaker: 70 amperage
- Min Circuit Ampacity: 50 amperage
- Phase: Single
- Refrigerant Model: R410A
- Voltage: 230V
- Product Depth: 39 inch
- Product Height: 48.2 inch
- Product Weight: 287 pound
- Product Width: 31 inch
- Water Connection 1: 2 inch
- UPC Code: 788379867393
Shipping, Installation & Warranty
Free Shipping: Most orders ship within 1 business day, unless otherwise noted.
Disclaimer: Professional installation (not included) is required, and proof of installation by a certified technician is needed to validate the factory warranty.
Warranty: Visit our warranty page or refer to the specific product user manual.
Disclaimer: Professional installation (not included) is required for warranty validation.
