Pentair 3 HP WhisperFloXF Single Speed Pump 3-Phase, 022018
TradeGrade
Pentair 022018 WhisperFloXF® XFK-12 3 Phase TEFC Premium Efficient High Performance Pump with Super-Duty Motor; 3 HP, 208-230/460V, 9.8-9.4/4.7 Amp
THE MOST POWERFUL, EFFICIENT WHISPERFLO® EVER.
The WhisperFloXF® pool pump was developed using the most advanced engineering tools: CFD (Computational Fluid Dynamics) and FEA (Finite Element Analysis). The proprietary impeller design delivers higher precision concentricity for increased efficiency. The proprietary hydraulic isolator smooths the water flow inside the volute, increasing the efficiency. With capabilities over 200 GPM, WhisperFloXF is an ideal choice for many residential and commercial applications, especially those involving water features, negative edges, and slides.
- Drop-in replacement for original WhisperFlo and optional riser plate enables easy Challenger replacement.
- A modular plumbing system means less need to cut and glue pipe
- External port threading and tool-free union nuts need only hand-tightening
- Easy-carry handle; easily removable, ergonomic lock ring; and see-through lid for easy basket inspection
- Upgraded dual-compartment motor for simplified field wiring
- Upgraded hydraulic isolator separates priming water from pumping water for faster priming, more turbulence-free flow and increased efficiency
- Upgraded union connectors included for connecting directly to 2.5" or 3" plumbing
Support Documents:
- WhisperFloXF High-Performance Pump
- Installation and Users Guide for Single-Phase
- Install Users Guide for 3-Phase
Pentair 022018 WhisperFloXF® XFK-12 Pump Specifications:
- Brand: Pentair
- Amps High Speed: 9.8
- Amps Low Speed: 4.7
- Application: Pool, Spa
- Weight: 60 pounds
- Green or Energy-Efficient Product: True
- Horsepower: Three horsepower
- Motor Speed: 1-Speed
- Service Factor: 1.15
- Service Factor HP: 3.45
- Standards Approvals: CSA Certified
- Voltage: 208V, 230V
- Commercial, Residential, or Professional: Commercial
- Flow Rate Max: 220 gal/min
- Motor Enclosure Type: Totally Enclosed Fan-cooled
- Phase: Three
- Voltage: 208V/230V/460V (3-Phase)
- Thrust HP: 3
- UPC Code: 788379851866
Three-Phase Single Speed Premium Efficiency with "Super-Duty" Motor: 022017, 022018, 022019.
Shipping, Installation & Warranty
Free Shipping: Most orders ship within 1 business day, unless otherwise noted.
Disclaimer: Professional installation (not included) is required, and proof of installation by a certified technician is needed to validate the factory warranty.
Warranty: Visit our warranty page or refer to the specific product user manual.
Disclaimer: Professional installation (not included) is required for warranty validation.
